Fusing Machine (SR-600) with continuous movement, the working width is 600 mm. The press has an “open side”, which makes possible gluing elements that wider than 600 mm. Adjustable pressure and pressing time. Independent temperature control of both the top and bottom heating elements, controlled by an electronic thermostat with programming function (show information about the desired temperature and the actual temperature.) The machine has the function of clearing belts and rollers squeegees.

Technical characteristics

Power supply: 380V, heater power: 6.6 kW, max. temperature: 220 ° C, max. pressure: 2.0 kg / cm max. belt moving speed: 8 m / min. Weight: 210 kg.
Supplied with a standard base on wheels.

Fusing Machine (SR-500)with continuous movement, the working width is 500 mm. The press has an “open side”, which makes possible gluing elements that wider than 500 mm. Adjustable pressure and pressing time. Independent temperature control of both the top and bottom heating elements, controlled by an electronic thermostat with programming function (show information about the desired temperature and the actual temperature.) The machine has the function of clearing belts and rollers squeegees.

Technical characteristics

Power supply: 230V, heater power: 5.4 kW, max. temperature: 220 ° C, max. pressure: 2.0 kg / cm max. belt moving speed: 8 m / min. Weight: 180 kg.

Supplied with a standard base on wheels.

The PL/T press with it’s well-built steel framework, is tough, safe, reliable and easy to operate.
With adjustable pressure and time setting and temperature set with a digital thermostat.

The machine has a safety device, which prevents the top closing accidentally.

SPECIFICATIONS
Power supply: 220 to 240 V
Plate size: 50 x 40 Inches
Plate heater power: 1750 W
Temperature: 0 to 230 ° C
Working time: from 0 to 90 sec.
Net Weight: 69 Kg

The PL/T press with it’s well-built steel framework, is tough, safe, reliable and easy to operate.
With adjustable pressure and time setting and temperature set with a digital thermostat.
The machine has a safety device, which prevents the top closing accidentally.
SPECIFICATIONS
Power supply: 220 to 240 VAC
Plate size: 90 x 40 cm
Plate heater power: 2250 W
Temperature: 0 to 230 ° C
Working time: from 0 to 90 sec.
Net Weight: 79 kg

The PL/T press with it’s well-built steel framework, is tough, safe, reliable and easy to operate.
With adjustable pressure and time setting and temperature set with a digital thermostat.
The machine has a safety device, which prevents the top closing accidentally.
SPECIFICATIONS
Power supply: 380 to 415 V
Plate size: 110 x 40 cm
Plate heater power: 2600 W
Temperature: 0 to 230 ° C
Working time: from 0 to 90 sec.
Net Weight: 94 kg

The PL/T press with it’s well-built steel framework, is tough, safe, reliable and easy to operate.
With adjustable manual pressure, time setting and temperature set with a digital thermostat.
The machine has a safety device, which prevents the top closing accidentally.
SPECIFICATIONS
Power supply: 380 V
Plate size: 125 x 50 cm
Plate heater power: 4250 W
Temperature: 0 to 230 ° C
Working time: from 0 to 90 sec.
Net weight: 106 kg
